Chapter 2 Installation and Setup
Chapter 2 Installation and Setup
Chapter 2 Installation and Setup
2-1 Checking the Included Items
The following it
ems are included with the machine. Make sure they are all presen
t and accounted for
.
Po
wer cord
USB cable
Collet
Hexagonal wrench
Hexagonal screw
drivers
Spanners
Z0 Sensor
Roland Soft
ware
Package CD-ROM
SRP Player CD-ROM
User’
s Manual
(this document)
SRP Play
er Installation
and Setup Guide
31
