4-3 Starting Cutting
64
Chapter 4 Getting Ready for and Performing Cutting Chapter 4 Getting Ready for and Performing Cutting
Chapter 4 Getting Ready for and Performing Cutting
Start Cutting (Output to the machine directly form the application)
When the machine receives the cutting data from the computer, the spindle begins to rotate and cutting
starts. The feed rate and the speed of spindle rotation are determined by the cutting data received.
Important !
Before starting the cutting, make sure of the following items. If there is a problem with any of these
items, the machine may operate in an unintended manner, causing the workpiece to be wasted or the
machine to be damaged.
Whether the output le is correct.
Whether the origin point is correct.
Whether the cutting condition matches the workpiece type.
Procedure
Close the front cover.
Use the software to output the
cutting data.
Using the Output File List
In addition to sending cutting data directly from the software, you can take cutting data that has been
made into a text le and import the le into VPanel.
P. 65, “Start Cutting (output via VPanel)”
To Next Page
