4-3 Starting Cutting
66
Chapter 4 Getting Ready for and Performing Cutting Chapter 4 Getting Ready for and Performing Cutting
Chapter 4 Getting Ready for and Performing Cutting
Click the [Cut] button on the
VPanel.
Click the [Add] button and open
the output le. Alternatively, drag
the output file to [Output File
List].
Output File List
This displays a list of registered output
les. When two or more output les are
present, they are executed sequentially,
one after another. Click [Delete] button
to delete the les.
Preview
This displays the contents of the output
le. (When the output le is in RML-1,
les may not be displayed.)
[Add] Button
Clicking this displays a window for select-
ing the output le.
[Save List] Button
You can save the list of output les and
output order as a list le.
Click [Output].
Starts the cutting.
Clicking [Test] enables executing a pro-
gram per line (only when the output le
is in NC code).
To Next Page
