Roland Octapad SPD-20X User Manual

1
15
Pad 1
Sound Parameters
• Instrument
• Level
• Pitch
• Decay
• Pan
• Velocity Curve
• Eect Send
MIDI Parameters
• Midi Channel
• Note Number
• Gate Time
• Program Change
MEMO
Pressing PATCH/VALUE [+] while holding down PATCH/VALUE [-] (or vice versa) causes the Patch
numbers to change more rapidly.
Connection to Audio Equipment
When you select a Patch, the sound assigned to each pad and the settings for MIDI, eect and pedal will
all change instantly. Try each of the 99 factory-preset Patches to hear the dierent possibilities.
To select Patches rst make sure you are in the Play mode. Then use the PATCH/VALUE [-] or [+] but-tons
to select Patches. The number of the selected Patch will appear in the display.
When you select a Patch, the settings for each pad are instantly changed
What is a Patch?
A Patch contains data determines how each pad sounds, settings for the effects and also MIDI
settings.
The SPD-20X can store 99 dierent Patches.
PATCH
02 Latin Set
Pad 2
External Pads
1-4
Pad 3 Pad 4
Pad 6Pad 5 Pad 7 Pad 8
Internal Pads 1-8
+
Patch 99
Patch 1
•
•
Hi-Hat Control PedalEects
Pad 1

Roland Octapad SPD-20X Specifications

General

Velocity Sensitivity	Yes
Pads	8
Presets	50
Effects	EQ
Display	LCD
MIDI	MIDI
Connectivity	MIDI
Outputs	Stereo (L/Mono, R)
Inputs	4 x External Trigger Inputs, Footswitch Jack
Power Supply	AC Adapter
