Roland Octapad SPD-20X User Manual

24
Adjusting the Volume (LEVEL)
Adjusting the Pitch (PITCH)
Adjusting the Stereo Position (PAN)
Adjusting the Decay (DECAY)
This parameter determines the volume (0–15). At a setting of 0 there will be no sound.
This parameter determines the pitch of the Instrument (-24 – +24). Each step will change the pitch
by asemitone (100 cents).
For some Instruments, raising the pitch beyond a certain point will not be heard.
This parameter adjusts the decay of the Instrument (-31–+31). Higher settings will result in a
longer decay time.
For some Instruments, raising the pitch beyond a certain point will not be possible.
Changing the decay setting for a Phrase Loop Instrument changes the attenuation time at the end of
the loop.
This parameter determines the stereo position of the Instrument (L7-Center-R7/Random). A setting
of L7 is far left, Center is in the middle, and R7 is far right. At the “Random” setting, the stereo
position will change randomly eachtime you strike the pad.
This parameter is meaningful only when the SPD-20X is connected to a stereo audio system.
NOTE
NOTE
NOTE
Level
Time
310-31
Right SpeakerLeft Speaker
Center
(Center)
7R7L

Roland Octapad SPD-20X Specifications

General

Velocity Sensitivity	Yes
Pads	8
Presets	50
Effects	EQ
Display	LCD
MIDI	MIDI
Connectivity	MIDI
Outputs	Stereo (L/Mono, R)
Inputs	4 x External Trigger Inputs, Footswitch Jack
Power Supply	AC Adapter
