Selecting and Adjusting Sounds (Sound Parameters)
Selecting a Sound (INST)
The parameters in the SOUND group (the sound parameters) allow you to modify the sound
assigned to each pad.
The SOUND group contains 7 parameters: INST, LEVEL, PITCH, DECAY, PAN, CURVE and FX SEND.
About Phrase Loop
Some Instruments are designed as Phrase Loops.
When you select a Phrase Loop, you don’t just hear single notes; instead, a short phrase typical
of that musical genre is played. You cannot play more than one Phrase Loop at the same time. To
force a Phrase Loop tostop sounding, select “MUTE” and strike the pad. No sound is heard from a
pad that has been set for “MUTE.”
Sound parameter settings for each pad are stored in each Patch.
Each sound assigned to a pad is called an Instrument. The SPD-20X contains 747 such Instruments,
and the Instrument assign settings determine which sounds will be played. The 747 Instruments
are grouped into the following categories.
The Hi-Hat Cymbals for pedal control “instruments PEDAL_HH 1 – PEDAL_HH 17” can be used eectively
only when a Hi-Hat controller (FD-8; separately sold) is used.
If the Instrument assign setting for any Pad is set to “OFF”, there will be no sound when you strike that
Pad.
If you make the Hold Pedal settings, then with some of the sounds, you can use the footswitch to sustain
the sound. For the instruments that can be lengthened with the footswitch, refer to Instrument List.
When an Instrument is selected, by pressing PATCH/VALUE [+] while holding down [-] (or viceversa), you
can jump to the next Instrument group.
MEMO
MEMO
No. From Instrument Category
001 B01 – B50 Bass Drum
051 S01 – S86 Snare Drum
137 T01 – T40 Tom-tom
177 h01 – h33 Hi-Hat Cymbal
210 H01 – H17 Hi-Hat Cymbal for pedal control
227 C01 – C36 Crash/Ride Cymbal
263 L01 – L78 Latin Percussion (Cuban, Brazilian)
341 i01 – i33 Indian Percussion
374 F01 – F37 African/Mid Eastern/Australian/Other Percussion
411 J01 – J51 Japanese/Korean/Chinese/Southeast Asian Percussion
462 O01 – O24 Orchestral Percussion
486 M01 – M59 Melodic Percussion/Melodic Instrument
545 A01 – A16 Analog Percussion (CR-78, TR-808, etc.)
561 D01 – D43 Dance Sounds
604 E01 – E46 Articial Sound Eects
650 N01 – N31 Natural Sounds, Human Voice
681 R01 – R20 Ambience, Reversed Sounds
701 I01 – I45 New Indian Percussion sounds to SPD-20X
746 MUTE Forces Phrase Loop Instrument to stop. No sound
747 OFF No sound
