What is a Pad Bank?
The 8 pads of the SPD-20X, together with 4 external pads (plus the 4 rims)—for a total of 16 pads—are
referred to as a pad bank. Each Patch contains two pad bank settings, A and B.
When you select a Patch, the PAD BANK indicator will show which pad bank the Patch uses. If the Layer
function (explained below) is used in that Patch, both PAD BANK indicators (A and B) will be lit.
Pad Bank B
Pad Bank A
4 Rims4 External Pads
Pad 3 Pad 4
Pad 7 Pad 8
Pad 1 Pad 2
Pad 5 Pad 6

Roland Octapad SPD-20X Specifications

General

Velocity Sensitivity	Yes
Pads	8
Presets	50
Effects	EQ
Display	LCD
MIDI	MIDI
Connectivity	MIDI
Outputs	Stereo (L/Mono, R)
Inputs	4 x External Trigger Inputs, Footswitch Jack
Power Supply	AC Adapter
