Roland Octapad SPD-20X User Manual

11
Attaching the SPD-20X to a Drum Stand
When you attach the unit to a drum stand (e.g. Roland PDS-10, APC-33: sold separately), please use the
pre-installed screws to x it up accordingly.
1
Using a phillips screwdriver, remove the four screws from the bottom of
the SPD-20X.
The screws included with the APC-33 cannot be used.
NOTE
2
Use the four screws you removed in step 1 to attach the stand holder to
the bottom of the SPD-20X.

Roland Octapad SPD-20X Specifications

General

Velocity Sensitivity	Yes
Pads	8
Presets	50
Effects	EQ
Display	LCD
MIDI	MIDI
Connectivity	MIDI
Outputs	Stereo (L/Mono, R)
Inputs	4 x External Trigger Inputs, Footswitch Jack
Power Supply	AC Adapter
