Roland RD-2000 Parameter Guide

Detailed Settings for Each Function
Selecting the Parts That Will Produce
Sound (PART SW)
Here you can specify whether or not performance data is to be
received from an external MIDI device.
Sound Generator Section
Part switch
Tone Zone 5 (5ch)
Tone
Zone 1 (1ch)
Tone Zone 6 (6ch)
Tone Zone 2 (2ch)
Tone Zone 7 (7ch)
Tone Zone 3 (3ch)
Tone Zone 8 (8ch)
Tone
Zone 4 (4ch)
Zone 9 (9ch)Tone
Tone
Zone 10 (10ch)
Tone Zone 11 (11ch)
Tone
Zone 12 (12ch)
Tone Zone 13 (13ch)
Tone Zone 14 (14ch)
Tone Zone 15 (15ch)
Tone Zone 16 (16ch)
MIDI
messages
from an
external
device
[MENU] button
0
Select “System”
0
[ENTER] button
0
“PART
SW” tab
Parameter Value Explanation
Part Switch
OFF, ON
(Part 1–Part 16)
Part Switch settings can be
made individually for each
part.
NOTE
Tone Color and eects are not available
for the parts received on channels 5–16.
They may sound dierently than the
sounds played on channels 1–4.
Making the System Compressor Settings
(COMPRESSOR)
This is a stereo compressor (limiter) that is applied to the nal
output.
With separate settings for the high-frequency range, midrange, and
low-frequency range, this reduces inconsistencies in volume levels
by compressing the sound when the volume exceeds a preset
volume level.
[MENU] button
0
Select “System”
0
[ENTER] button
0
“COMPRESSOR” tab
Parameter Value Explanation
Compressor
Switch
OFF, ON Turns the compressor on/o.
Parameter Value Explanation
Type
Compressor Type
When you change this parameter, the
Compressor parameters will be automatically
adjusted to the optimal values.
You can make the settings easily by rst setting
the Compressor Type and then changing only
the necessary parameters.
HARD COMP Applies strong compression.
SOFT COMP Applies mild compression.
LOW BOOST Boosts the low end.
MID BOOST Boosts the midrange.
HI BOOST Boosts the high end.
USER The saved settings are written.
Split Freq Low
40, 50, 63, 80,
100, 125, 160,
200, 250, 315,
400, 500, 630,
800 [Hz]
Sets the frequency separating
the low-frequency range
(LOW) and midrange (MID).
Split Freq High
400, 500, 630,
800, 1000,
1250, 1600,
2000, 2500,
3150, 4000,
5000, 6300,
8000 [Hz]
Sets the frequency separating
the high-frequency range
(HIGH) and midrange (MID).
Common to High, Mid, and Low
Parameter Value Explanation
Level
0–24 dB
(1 dB Step)
Output Level
Attack Time 0–100
Sets the time it takes until the
level is compressed after the
input exceeds the Threshold.
Release Time 0–100
Sets the time it takes for the
compression to be released
after the input falls below the
Threshold.
Threshold
-60 dB–0 dB
(1 dB Step)
Sets the level at which
compression begins.
Ratio
1:1.0, 1:1.1,
1:1.2, 1:1.4,
1:1.6, 1:1.8,
1:2.0, 1:2.5,
1:3.2, 1:4.0,
1:5.6, 1:8.0,
1:16, 1:INF
Compression Ratio
INFORMATION
This shows the RD-2000’s system program version and information
about additional sounds.
27

Roland RD-2000 Specifications

General

Pedal jack	Yes
Sound effects	Compression, Equalization, Modulation, Reverberation
Tones quantity	1100
Built-in speaker(s)	No
Number of front panel sliders	9
Reverberation effects quantity	6
Preset programs quantity	300
Keyboard name	PHA-50
Keys quantity	88 keys
Display resolution	256 x 80 pixels
Power consumption (max)	23 W
Audio (L/R) out	2
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	6.3 mm
Product color	Black
Cables included	AC

Weight and Dimensions

Depth	367 mm
Width	1412 mm
Height	140 mm
Weight	21700 g
