Roland RD-2000 - Auto Pan; Ring Modulator; Tremolo

43
Modulation FX Parameters
Parameter Value Explanation
Mode 1, 2, 3, 4
Higher values will produce a
deeper phaser eect.
Speed # -100–+100
Speed at which to raise or
lower the frequency at which
the sound is modulated
(+: upward / -: downward)
Resonance # 0–127 Amount of feedback
Mix # 0–127
Volume of the phase-shifted
sound
Pan # L64–63R Panning of the output sound
Low Gain -15–+15 [dB]
Gain of the low frequency
range
High Gain -15–+15 [dB]
Gain of the high frequency
range
Level 0–127 Output volume
22: RING MODULATOR
This is an eect that applies amplitude modulation (AM) to the
input signal, producing bell-like sounds. You can also change the
modulation frequency in response to changes in the volume of the
sound sent into the eect.
L in
R in
L out
R out
Ring Mod
2-Band EQ
2-Band EQ
Ring Mod
Parameter Value Explanation
Switch OFF, ON Turns the eect on/o.
Depth Knob
FREQUENCY,
SENS,
BALANCE
Species the parameter
that is controlled by the
MODULATION FX [DEPTH]
knob.
Rate Knob
Species the parameter
that is controlled by the
MODULATION FX [RATE]
knob.
Feedback
Knob
OFF,
FREQUENCY,
SENS,
BALANCE
Species the parameter
that is controlled by the
MODULATION FX [FEEDBACK]
knob.
Frequency # 0–127
Adjusts the frequency at
which modulation is applied.
Sens # 0–127
Adjusts the amount of
frequency modulation
applied.
Polarity UP, DOWN
Determines whether the
frequency modulation moves
towards higher frequencies
(UP) or lower frequencies
(DOWN).
Low Gain -15–+15 [dB]
Gain of the low frequency
range
High Gain -15–+15 [dB]
Gain of the high frequency
range
Balance #
D100:0W–
D0:100W
Volume balance between
the direct sound (D) and the
eect sound (W)
Level 0–127 Output level
23: TREMOLO
Cyclically modulates the volume to add tremolo eect to the
sound.
L in
R in
L out
R out
Tremolo
2-Band EQ
2-Band EQ
Tremolo
Parameter Value Explanation
Switch OFF, ON Turns the eect on/o.
Depth Knob
RATE,
DEPTH,
MOD WAVE
Species the parameter
that is controlled by the
MODULATION FX [DEPTH]
knob.
Rate Knob
Species the parameter
that is controlled by the
MODULATION FX [RATE]
knob.
Feedback
Knob
OFF,
RATE,
DEPTH,
MOD WAVE
Species the parameter
that is controlled by the
MODULATION FX [FEEDBACK]
knob.
Mod Wave
TRI,
SQR,
SIN,
SAW1,
SAW2
Modulation wave
TRI: triangle wave
SQR: square wave
SIN: sine wave
SAW1/2: sawtooth wave
SAW1 SAW2
Rate
(sync sw)
OFF, ON
If this is ON, the modulation
is synchronized to the tempo
of the rhythm (owner’s
manual: p. 24).
Rate (Hz) #/
Rate (note) #
0.05–10.00 [Hz]
Frequency of the change
note (p. 60)
Depth # 0–127
Depth to which the eect is
applied
Low Gain -15–+15 [dB] Gain of the low range
High Gain -15–+15 [dB] Gain of the high range
Level 0–127 Output Level
24: AUTO PAN
Cyclically modulates the stereo location of the sound.
L in
R in
L out
R out
Auto Pan
2-Band EQ
2-Band EQ
Auto Pan
Parameter Value Explanation
Switch OFF, ON Turns the eect on/o.
Depth Knob
RATE,
DEPTH,
MOD WAVE
Species the parameter
that is controlled by the
MODULATION FX [DEPTH]
knob.
Rate Knob
Species the parameter
that is controlled by the
MODULATION FX [RATE]
knob.
