69
System Compressor Parameters
Parameter Value Explanation
Compressor
Switch
OFF, ON Turns the compressor on/o .
Type
When you change this parameter, the
Compressor parameters will be automatically
adjusted to the optimal values.
You can make the settings easily by rst setting
the Compressor Type and then changing only the
necessary parameters.
HARD COMP Applies strong compression.
SOFT COMP Applies mild compression.
LOW BOOST Boosts the low end.
MID BOOST Boosts the midrange.
HI BOOST Boosts the high end.
USER
The saved settings are
written.
Split Freq
Low
40, 50, 63, 80, 100,
125, 160, 200, 250,
315, 400, 500, 630,
800 [Hz]
Sets the frequency
separating the low-frequency
range (LOW) and midrange
(MID).
Split Freq
High
400, 500, 630, 800,
1000, 1250, 1600,
2000, 2500, 3150,
4000, 5000, 6300,
8000 [Hz]
Sets the frequency separating
the high-frequency range
(HIGH) and midrange (MID).
Common to Low, Mid, and High
Parameter Value Explanation
Level
0–24 [dB]
(1 dB Step)
Output Level
Attack Time 0–100
Sets the time it takes until the
level is compressed after the
input exceeds the Threshold.
Release Time 0–100
Sets the time it takes for the
compression to be released
after the input falls below the
Threshold.
Threshold
-60–0 [dB]
(1 dB Step)
Sets the level at which
compression begins.
Ratio
1:1.0, 1:1.1, 1:1.2,
1:1.4, 1:1.6, 1:1.8,
1:2.0, 1:2.5, 1:3.2,
1:4.0, 1:5.6, 1:8.0,
1:16, 1:INF
Compression Ratio
This is a stereo compressor (limiter) that is applied to the nal output.
With separate settings for the high-frequency range, midrange, and low-frequency range, this reduces inconsistencies in volume levels by
compressing the sound when the volume exceeds a preset volume level.
