Rotax 912 Series - Page 174

d04927.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
79-00-00
page 14
August 01/2012
Graphic
Connection
Fig. 8 08634
Part Function
1 Slip-on connection
2 Adaptor 3/4-16 UNF (AN-8)
3 Hose nipple 10 DIN 7642
4 Banjo bolt M16x1.5x28
5 Screw connection
3
1
4
2
5
4
