INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
10-10-00
page 11
August 01/2012
1)
up to gearbox S/N 28986
2)
starting from gearbox S/N 28987
attachment point
thread
size
max. usable thread
length mm/in.
L1 M10 25 mm/0.98 in.
R1
L2 M10 25 mm/0.98 in.
R2
L3 M10 25 mm/0.98 in.
R3
L4 M10 19 mm /0.75 in.
1)
16 mm /0.63 in.
2)
R4
