QUICK INSTALLATION GUIDE: SNC-4302
To operate the IP dome camera, please follow these steps:
1. Install the camera in the desired location.
Connector
Definition
Description
1
Reset button
Reset to factory default.
2 Lens
Turn the lens clockwise/counter-
clockwise to adjust the focus.
3
Focus fixed screw
Loosen the screw to adjust the lens.
4
Tilt fixed screw
Loosen the screw to adjust the tilt angle.
5
Micro SD card slot
For video recording storage.
2. Connect the camera to power using PoE (PoE switch or PoE injector required).
The SANTEC SNC-4302 can only be supplied with power via PoE.
3. Connect the camera to the network using a LAN cable.
The network LED lights up in orange.
4. Insert the CD (included in the delivery) into your PC/laptop
and install the IP-finder.
5. The IP-finder displays an IP address for the camera. Double-click on the IP address
and the Internet Explorer comes up automatically. In case this doesn’t work, you may
also enter the IP address (as shown by the IP-finder) manually into the Internet
Explorer. Using the IP-finder, another IP address can be assigned to the camera, if
required.
Note:
The camera comes with a default IP address:
Default IP address: 192.168.1.168 (or by DHCP, if available)
User name: admin
Pass word: 9999
Please refer to the following chapters in this user manual for further information on camera
configurations.
1. Prepare a PC/laptop with an Ethernet link to the network.
2. Connect the LAN port (RJ45) of the camera to a network
switch/hub.
3. Check the network LED status.
