Santec SNC-3302 - Snc-6302, Snc-6312 Irh, Snc-6315 Irh, Snc-6323 Irh

User manual
SANTEC IP cameras
_________________________________________________________________________________
- 73 -
5. Technical specifications: SNC-6302, SNC-6312IRH, SNC-6315IRH
Camera SNC-6302 SNC-6312IRH SNC-6315IRH SNC-6323IRH
Camera type
Full HD IP day/night
dome camera
Full HD IP day/night IR dome camera
2 MP 5 MP 3 MP
Sensor type 1/2.7” Progressive Scan CMOS Sensor
1/2.5” Progressive
Scan CMOS
Sensor
1/2.8” Progressive
Scan CMOS
Sensor
Resolution (pixel)
Max. 2 MP
(1920 x 1080)
Max. 5 MP
(2592x1944)
max. 2MP at
MJPEG
Max. 3 MP
(2048x1536)
Video codec H.264 / MJPEG
Max. frame rate 25 fps at 2 MP (1920 x 1080)
12 fps at 5 mP
15 fps at 3 MP
25 fps at 2 MP
15 fps at 3 MP
25 fps at 2 MP
Number of video streams 4
Lens mount Internal
Iris control DC
Lens type
Built-in manual vario
lens
Motorised DC vario lens
Focal length 3 - 9 mm / F1.2
Angle of view (horizontal) 36° - 104°
36-105° at 5MP
29-83° at 3 MP
27-79° at 2 MP
29-83° at 3 MP
27-79° at 2 MP
Sensitivity
0.2 (colour) / 0.02
(black/white)
0.2 (colour) / 0.02 (black/white)/
0.0 (IR-LED)
IR cut filter Mechanical
Day/night mode adjustment Auto, colour, black/white
Automatic Gain Control (AGC) Yes
Digital Noise Reduction (DNR) 3DNR, SPQ
Shutter speed 1-1/10000 sec.
White balance AWB, ATW, manual
Backlight compensation BLC
Wide Dynamic Range (WDR) 4 levels, digital
Digital zoom Yes
Mirroring (vertical) Yes
Motion detection Yes
Privacy zones Yes, 5 zones
Tampering alarm Yes
Camera title Yes
Video output BNC, 75 Ohm, 1 Vpp
Audio support Yes, 2-way
Audio input/output 1 / 1 (3.5 mm phone jack)
Audio codec G.711 / G.726
Alarm contacts I/O 1 / 1
(continue on next page)
