Satec PM172P Reference Guide

23
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+15 0x108F Not used INT16 R
7336-7368 1-Second Phase Values
+0 0x1100 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x1101 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x1102 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x1103 I1 Current 0-Imax U2 UINT16 R
+4 0x1104 I2 Current 0-Imax U2 UINT16 R
+5 0x1105 I3 Current 0-Imax U2 UINT16 R
+6 0x1106 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x1107 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x1108 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x1109 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x110A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x110B kvar L3 -Pmax-Pmax U3 INT16 R
+12 0x110C kVA L1 0-Pmax U3 UINT16 R
+13 0x110D kVA L2 0-Pmax U3 UINT16 R
+14 0x110E kVA L3 0-Pmax U3 UINT16 R
+15 0x110F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x1110 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x1111 Power factor L3 -1.000-1.000 0.001 INT16 R
+18 0x1112 V1/V12 Voltage THD 0-999.9 0.1% UINT16 R
1
3-sec value
+19 0x1113 V2/V23 Voltage THD 0-999.9 0.1% UINT16 R
1
3-sec value
+20 0x1114 V3/V31 Voltage THD 0-999.9 0.1% UINT16 R
1
3-sec value
+21 0x1115 I1 Current THD 0-999.9 0.1% UINT16 R 3-sec value
+22 0x1116 I2 Current THD 0-999.9 0.1% UINT16 R 3-sec value
+23 0x1117 I3 Current THD 0-999.9 0.1% UINT16 R 3-sec value
+24 0x1118 I1 K-Factor 1.0-999.9 0.1 UINT16 R 3-sec value
+25 0x1119 I2 K-Factor 1.0-999.9 0.1 UINT16 R 3-sec value
+26 0x111A I3 K-Factor 1.0-999.9 0.1 UINT16 R 3-sec value
+27 0x111B I1 Current TDD 0-100.0 0.1% UINT16 R 3-sec value
+28 0x111C I2 Current TDD 0-100.0 0.1% UINT16 R 3-sec value
+29 0x111D I3 Current TDD 0-100.0 0.1% UINT16 R 3-sec value
+30 0x111E V12 Voltage 0-Vmax U1 UINT16 R
+31 0x111F V23 Voltage 0-Vmax U1 UINT16 R
+32 0x1120 V31 Voltage 0-Vmax U1 UINT16 R
7456-7459 1-Second Total Values
+0 0x1400 Total kW -Pmax-Pmax U3 INT16 R
+1 0x1401 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x1402 Total kVA 0-Pmax U3 UINT16 R
+3 0x1403 Total PF -1.000-1.000 0.001 INT16 R
+4 0x1404 Total PF lag 0-1.000 0.001 UINT16 R
+5 0x1405 Total PF lead 0-1.000 0.001 UINT16 R
+5 0x1406 Total kW import 0-Pmax U3 UINT32 R
