Satec PM172P Reference Guide

27
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+14 0x290E kVA L3 0-Pmax U3 UINT16 R
+15 0x290F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x2910 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x2911 Power factor L3 -1.000-1.000 0.001 INT16 R
8336-8343 Harmonic Total Values 4-cycle values
+0 0x2A00 Total fundamental kW -Pmax-Pmax U3 INT16 R
+1 0x2A01 Total fundamental kvar -Pmax-Pmax U3 INT16 R
+2 0x2A02 Total fundamental kVA 0-Pmax U3 UINT16 R
+3 0x2A03 Total fundamental PF -1.000-1.000 0.001 INT16 R
+4 0x2A04
Total harmonic kW
EH
-Pmax-Pmax U3 INT16 R
+5 0x2A05 Not used INT16 R
+6 0x2A06
Total harmonic kVA
EH
0-Pmax U3 UINT16 R
+7 0x2A07 Not used INT16 R
8416-8445 Minimum 1-Cycle Phase Values
+0 0x2C00 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x2C01 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x2C02 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x2C03 I1 Current 0-Imax U2 UINT16 R
+4 0x2C04 I2 Current 0-Imax U2 UINT16 R
+5 0x2C05 I3 Current 0-Imax U2 UINT16 R
+6-17 0x2C06-
0x2C11
Not used 0 INT16 R
+18 0x2C12 V1/V12 Voltage THD 0-9999 0.1% UINT16 R
1
4-cycle value
+19 0x2C13 V2/V23 Voltage THD 0-9999 0.1% UINT16 R
1
4-cycle value
+20 0x2C14 V3/V31 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+21 0x2C15 I1 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+22 0x2C16 I2 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+23 0x2C17 I3 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+24 0x2C18 I1 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+25 0x2C19 I2 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+26 0x2C1A I3 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+27 0x2C1B I1 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+28 0x2C1C I2 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+29 0x2C1D I3 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
8456-8459 Minimum 1-Cycle Total Values
+0 0x2D00 Total kW -Pmax-Pmax U3 INT16 R
+1 0x2D01 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x2D02 Total kVA 0-Pmax U3 UINT16 R
+3 0x2D03 Total PF 0-1.000 0.001 UINT16 R Absolute value
8496-8498 Minimum 1-Cycle Auxiliary Values
+0 0x2E00 Not used U2 UINT16 R
+1 0x2E01 In Current 0-Imax U2 UINT16 R
+2 0x2E02 Frequency 0-Fmax 0.01Hz UINT16 R
