Satec PM172P Reference Guide

41
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+4,5 0x2D02 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x2D03 Total PF 0-1000
×0.001
UINT32 R Absolute value
17664-17669 Minimum 1-Cycle Auxiliary Values
+0,1 0x2E00 Not used UINT32 R
+2,3 0x2E01 In Current 0-Imax U2 UINT32 R
+4,5 0x2E02 Frequency 0-Fmax
×0.01Hz
UINT32 R
18432-18491 Maximum 1-Cycle Phase Values
+0,1 0x3400 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
+2,3 0x3401 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
+4,5 0x3402 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
+6,7 0x3403 I1 Current 0-Imax U2 UINT32 R
+8,9 0x3404 I2 Current 0-Imax U2 UINT32 R
+10,11 0x3405 I3 Current 0-Imax U2 UINT32 R
+12-35 0x3406-
0x3411
Not used 0 INT32 R
+36,37 0x3412 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+38,39 0x3413 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+40,41 0x3414 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+42,43 0x3415 I1 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+44,45 0x3416 I2 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+46,47 0x3417 I3 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+48,49 0x3418 I1 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
+50,51 0x3419 I2 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
+52,53 0x341A I3 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
+54,55 0x341B I1 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
+56,57 0x341C I2 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
+58,59 0x341D I3 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
18560-18567 Maximum 1-Cycle Total Values
+0,1 0x3500 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x3501 Total kvar -Pmax-Pmax U3 INT32 R
+4,5 0x3502 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x3503 Total PF 0-1000
×0.001
UINT32 R Absolute value
18688-18693 Maximum 1-Cycle Auxiliary Values
+0,1 0x3600 Not used UINT32 R
+2,3 0x3601 In Current 0-Imax U2 UINT32 R
+4,5 0x3602 Frequency 0-Fmax
×0.01Hz
UINT32 R
18816-18849 Maximum Demands
+0,1 0x3700 V1/V12 Maximum volt demand 0-Vmax U1 UINT32 R
1
+2,3 0x3701 V2/V23 Maximum volt demand 0-Vmax U1 UINT32 R
1
+4,5 0x3702 V3/V31 Maximum volt demand 0-Vmax U1 UINT32 R
1
+6,7 0x3703 I1 Maximum ampere demand 0-Imax U2 UINT32 R
+8,9 0x3704 I2 Maximum ampere demand 0-Imax U2 UINT32 R
+10,11 0x3705 I3 Maximum ampere demand 0-Imax U2 UINT32 R
