Satec PM172P Reference Guide

71
3.9 File Transfer Registers
E
Address Point ID Description Options/Range Units Type R/W Notes
File Allocation Status Registers
3500,3501 File allocation map (bitmap) F6 UINT32 R Bits set to 1 indicate that the
memory is allocated to the
designated files
3502,3503 Reserved 0 UINT32 R
3504,3505 Daily profile log sections map (bitmap) F7 UINT32 R Bits set to 1 indicate that the
corresponding sections are allocated
in the Data log #8 file to the
designated energy/maximum
demand registers
3506,3507 File memory size, Bytes 1040384 UINT32 R
3508,3509 Free file memory size, Bytes 0-1040384 UINT32 R
3510 Total number of records in the Event log file 0-65535 UINT16 R
3511 Total number of records in the Data log #1 file 0-65535 UINT16 R
3512 Total number of records in the Data log #2 file 0-65535 UINT16 R
3513 Total number of records in the Data log #3 file 0-65535 UINT16 R
3514 Total number of records in the Data log #4 file 0-65535 UINT16 R
3515 Total number of records in the Data log #5 file 0-65535 UINT16 R
3516 Total number of records in the Data log #6 file 0-65535 UINT16 R
3517 Total number of records in the Data log #7 file 0-65535 UINT16 R
3518 Total number of records in the Data log #8 file 0-65535 UINT16 R
3519-3526 Reserved 0 UINT16 R
3527 Total number of records in the Waveform log #1 file 0-65535 UINT16 R
3528 Total number of records in the Waveform log #2 file 0-65535 UINT16 R
3529 Number of new records in the Event log file 0-65535 UINT16 R
3530 Number of new records in the Data log #1 file 0-65535 UINT16 R
3531 Number of new records in the Data log #2 file 0-65535 UINT16 R
3532 Number of new records in the Data log #3 file 0-65535 UINT16 R
3533 Number of new records in the Data log #4 file 0-65535 UINT16 R
3534 Number of new records in the Data log #5 file 0-65535 UINT16 R
3535 Number of new records in the Data log #6 file 0-65535 UINT16 R
3536 Number of new records in the Data log #7 file 0-65535 UINT16 R
3537 Number of new records in the Data log #8 file 0-65535 UINT16 R
3538-3545 Reserved 0 UINT16 R
3546 Number of new records in the Waveform log #1 file 0-65535 UINT16 R
3547 Number of new records in the Waveform log #2 file 0-65535 UINT16 R
File Transfer Control/Status Registers
28160-28927
1
+0 File status (bitmap) F4 UINT16 R
+1 Number of records logged in the file 0 to 65535 UINT16 R
