33
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
11616 0x7C00 Setpoint Status (bitmap) 0x0000-0xFFFF UINT16 R
NOTES:
Energy and Power demand readings are only available in the meters with suffixes E and EH.
1
Voltage and Voltage Harmonics Readings:
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
When the 4LN3, 4LL3, 3LN3, 3LL3, 3BLN3 or 3BLL3 wiring mode is selected, the voltage harmonics will be line-to-neutral; for any other wiring mode, they will be line-to-line.
2
For volts, amps, power and frequency scales and units refer to Section 4 ”Data Scales and Units”. For analog data scaling formulas and examples, see Section 2.6.1, “16-bit Scaled Integer
Format”.
3
Harmonic angles are referenced to the fundamental voltage harmonic H01 on phase L1.
