Satec PM172P Reference Guide

81
Format Code Value Description Notes
Summary/TOU Energy Register Source ID
0x0000 None
0x0700-0x0701 Pulse input DI1-DI2
0x1700
kWh import
0x1701 kWh export
0x1704 kvarh import
0x1705 kvarh export
F11
0x1708 kVAh total
Setpoint Trigger Parameters ID
0x0000 None (condition is not active)
Voltage Disturbance
EH
0x0100 Voltage disturbance
Event Flags
EH
0x0300 Event flag #1 ON
0x0301 Event flag #2 ON
0x0302 Event flag #3 ON
0x0303 Event flag #4 ON
0x0304 Event flag #5 ON
0x0305 Event flag #6 ON
0x0306 Event flag #7 ON
0x0307 Event flag #8 ON
0x8300 Event flag #1 OFF
0x8301 Event flag #2 OFF
0x8302 Event flag #3 OFF
0x8303 Event flag #4 OFF
0x8304 Event flag #5 OFF
0x8305 Event flag #6 OFF
0x8306 Event flag #7 OFF
0x8307 Event flag #8 OFF
Internal Events
E
0x0400 kWh import pulse
0x0401 kWh export pulse
0x0403 kvarh import pulse
0x0404 kvarh export pulse
0x0405 kvarh total pulse
0x0406 kVAh total pulse
0x0407 Start new demand interval
0x0408 Start new tariff interval
0x0409 Start new volt/ampere demand interval
0x040A Start new sliding window demand interval
Timers
E
0x0500 Timer #1
0x0501 Timer #2
Status Inputs
0x0600 Status input #1 ON
0x0601 Status input #2 ON
0x8600 Status input #1 OFF
0x8601 Status input #2 OFF
Pulse Inputs
0x0700 Pulse input #1
0x0701 Pulse input #2
Relays
0x0800 Relay #1 ON
0x0801 Relay #2 ON
0x8800 Relay #1 OFF
0x8801 Relay #2 OFF
Phase Reversal
4
0x8901 Positive phase rotation reversal
0x8902 Negative phase rotation reversal
Pulse Counters
0x0A00 High pulse counter #1
0x0A01 High pulse counter #2
0x0A02 High pulse counter #3
0x0A03 High pulse counter #4
Time and Date Parameters
E
F12
0x0B02 Day of week
