Satec PM172P Reference Guide

29
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+12 0x370C Not used UINT16 R
+13 0x370D Not used UINT16 R
+14 0x370E Not used UINT16 R
+15 0x370F Maximum kW export sliding window demand 0-Pmax U3 UINT16 R
+16 0x3710 Maximum kvar export sliding window demand 0-Pmax U3 UINT16 R
7200-7211 Maximum Harmonic Demands
+0 0x3880 V1/V12 THD demand 0-999.9 0.1% UINT16 R
1
+1 0x3881 V2/V23 THD demand 0-999.9 0.1% UINT16 R
1
+2 0x3882 V3/V31 THD demand 0-999.9 0.1% UINT16 R
1
+3 0x3883 Not used UINT16 R
+4 0x3884 I1 THD demand 0-999.9 0.1% UINT16 R
+5 0x3885 I2 THD demand 0-999.9 0.1% UINT16 R
+6 0x3886 I3 THD demand 0-999.9 0.1% UINT16 R
+7 0x3887 Not used UINT16 R
+8 0x3888 I1 TDD demand 0-100.0 0.1% UINT16 R
+9 0x3889 I2 TDD demand 0-100.0 0.1% UINT16 R
+10 0x388A I3 TDD demand 0-100.0 0.1% UINT16 R
+11 0x388B Not used UINT16 R
9016-9017 Scaled Analog Inputs
+0 0x3B00 Analog input AI1 AI1min-AI1Max UINT16 R
+1 0x3B01 Analog input AI2 AI2min-AI2Max UINT16 R
9036-9037 Raw Analog Inputs
+0 0x3B80 Analog input AI1 0-4095 UINT16 R
+1 0x3B81 Analog input AI2 0-4095 UINT16 R
9056-9057 TOU Parameters
E
+0 0x3C00 Active tariff 0-7 UINT16 R/W
+1 0x3C01 Active profile 0-15:
0-3 = Season 1 Profile #1-4,
4-7 = Season 2 Profile #1-4,
8-11 = Season 3 Profile #1-4,
12-15 = Season 4 Profile #1-4
UINT16 R/W
9076-9077 Scaled Analog Outputs
+0 0x3C80 Analog output AO1 0-4095 UINT16 R/W
+1 0x3C81 Analog output AO2 0-4095 UINT16 R/W
9096-9111 TOU Energy Register #1
E
+0,1 0x3D00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3D01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3D07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9136-9151 TOU Energy Register #2
E
+0,1 0x3E00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3E01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
