Satec PM172P Reference Guide

40
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+16,17 0x2908 kW L3 -Pmax-Pmax U3 INT32 R
+18,19 0x2909 kvar L1 -Pmax-Pmax U3 INT32 R
+20,21 0x290A kvar L2 -Pmax-Pmax U3 INT32 R
+22,23 0x290B kvar L3 -Pmax-Pmax U3 INT32 R
+24,25 0x290C kVA L1 0-Pmax U3 UINT32 R
+26,27 0x290D kVA L2 0-Pmax U3 UINT32 R
+28,29 0x290E kVA L3 0-Pmax U3 UINT32 R
+30,31 0x290F Power factor L1 -1000-1000
×0.001
INT32 R
+32,33 0x2910 Power factor L2 -1000-1000
×0.001
INT32 R
+34,35 0x2911 Power factor L3 -1000-1000
×0.001
INT32 R
17152-17164 Harmonic Total Values 4-cycle values
+0,1 0x2A00 Total fundamental kW -Pmax-Pmax U3 INT32 R
+2,3 0x2A01 Total fundamental kvar -Pmax-Pmax U3 INT32 R
+4,5 0x2A02 Total fundamental kVA 0-Pmax U3 UINT32 R
+6,7 0x2A03 Total fundamental PF -1000-1000
×0.001
INT32 R
+8,9 0x2A04
Total harmonic kW
EH
-Pmax-Pmax U3 INT32 R
+10,11 0x2A05 Not used INT32 R
+12,13 0x2A06
Total harmonic kVA
EH
0-Pmax U3 UINT32 R
+14,15 0x2A07 Not used INT32 R
17408-17467 Minimum 1-Cycle Phase Values
+0,1 0x2C00 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
+2,3 0x2C01 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
+4,5 0x2C02 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
+6,7 0x2C03 I1 Current 0-Imax U2 UINT32 R
+8,9 0x2C04 I2 Current 0-Imax U2 UINT32 R
+10,11 0x2C05 I3 Current 0-Imax U2 UINT32 R
+12-35 0x2C06-
0x2C11
Not used 0 INT32 R
+36,37 0x2C12 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+38,39 0x2C13 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+40,41 0x2C14 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+42,43 0x2C15 I1 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+44,45 0x2C16 I2 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+46,47 0x2C17 I3 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+48,49 0x2C18 I1 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
+50,51 0x2C19 I2 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
+52,53 0x2C1A I3 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
+54,55 0x2C1B I1 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
+56,57 0x2C1C I2 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
+58,59 0x2C1D I3 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
17536-17543 Minimum 1-Cycle Total Values
+0,1 0x2D00 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x2D01 Total kvar -Pmax-Pmax U3 INT32 R
