Satec PM172P Reference Guide

53
3.6 Device Control and Status Registers
Address Point ID Description Options/Range Units Type R/W Notes
Device Restart Register
2560 Warm restart of the device 0 when read,
0xFFFF when written = restart the
device
UINT16 R/W
Device Authorization Registers
2575 When write: 4-digit password. When read: 0 = access
permitted, -1 = authorization required.
0-9999 (write)
0/-1 (read)
INT16 R/W
44378-44379 When write: 8-digit password. When read: 0 = access
permitted, -1 = authorization required.
0 - 99999999 (write)
0/-1 (read)
INT32 R/W
Event Flags Control
EH
2916-2923
2916 Event Flag #1 Status 0-1 UINT16 R/W
2917 Event Flag #2 Status 0-1 UINT16 R/W
2918 Event Flag #3 Status 0-1 UINT16 R/W
2919 Event Flag #4 Status 0-1 UINT16 R/W
2920 Event Flag #5 Status 0-1 UINT16 R/W
2921 Event Flag #6 Status 0-1 UINT16 R/W
2922 Event Flag #7 Status 0-1 UINT16 R/W
2923 Event Flag #8 Status 0-1 UINT16 R/W
Remote Relay Control
3244-3245
+0 Remote relay command 0 = remove a remote command
1 = operate relay
2 = remove a remote command and
release a locally latched relay
UINT16 W
3244 RO1 Control
3245 RO2 Control
Device Reset/Clear Registers
3404 Clear total energy registers 0 UINT16 W
3405 Clear total maximum demand registers 0 = Clear all maximum demands
1 = Clear power demands
E
2 = Clear volt, ampere and
harmonic demands
UINT16 W
3406
Clear TOU energy registers
E
0 UINT16 W
3407
Clear TOU maximum demand registers
E
0 UINT16 W
3408 Clear pulse counters 0 = Clear all counters
1-4 = Clear counter #1-#4
UINT16 W
3409 Clear Min/Max log 0 UINT16 W
3410
Clear event log
E
0 UINT16 W
3411
Clear data log
E
0-7 = Clear Data log #1-#8 UINT16 W
