Satec PM172P Reference Guide

73
Address Point ID Description Options/Range Units Type R/W Notes
28840-28847 Daily Profile Log, Max. Demand Reg.#6 control UINT16 R
28848-28855 Daily Profile Log, Max. Demand Reg.#7 control UINT16 R
28856-28823 Daily Profile Log, Max. Demand Reg.#8 control UINT16 R
28824-28927 Reserved UINT16 R
Event Log File Transfer Registers
29440-29559
Event Record Structure
+0 Record status (bitmap) F5 UINT16 R
+1 Record sequence number 0 to 65535 (increments modulo
65536)
UINT16 R
+2,3 Record time, sec F1 s UINT32 R
+4 Record time, fractional seconds, ms 0-999 ms UINT16 R
+5 Event point/cause ID F19 UINT16 R
+6,7 Log value UINT32 R 32-bit non-scaled register
+8 Event effect F20 UINT16 R
+9 Reserved 0 UINT16 R
Event Log Transfer Blocks
29440-29449 Event log record #1 R
29450-29459 Event log record #2 R
29460-29469 Event log record #3 R
29470-29479 Event log record #4 R
29480-29489 Event log record #5 R
29490-29499 Event log record #6 R
29500-29509 Event log record #7 R
29510-29519 Event log record #8 R
29520-29529 Event log record #9 R
29530-29539 Event log record #10 R
29540-29549 Event log record #11 R
29550-29559 Event log record #12 R
Data Log File Transfer Registers
29696-32895
Data Log Record Structure
+0 Record status (bitmap) F5 UINT16 R
+1 Record sequence number 0 to 65535 (increments modulo
65536)
UINT16 R
+2,3 Record time, sec F1 sec UINT32 R
+4 Record time, fractional seconds, ms 0-999 ms UINT16 R
+5 Trigger event ID 0=Profile log file, 1-16=SP1-SP16 UINT16 R
+6,7 Parameter #1 value INT32 R 32-bit non-scaled register
+8,8 Parameter #2 value INT32 R 32-bit non-scaled register
+10,11 Parameter #3 value INT32 R 32-bit non-scaled register
+12,13 Parameter #4 value INT32 R 32-bit non-scaled register
+14,15 Parameter #5 value INT32 R 32-bit non-scaled register
