Satec PM172P Reference Guide

50
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
+48,49
+50,51
0x3737 Not used
Timestamp
UINT32
UINT32
R
R
+52,53
+54,55
0x370D Not used
Timestamp
UINT32
UINT32
R
R
+56,57
+58,59
0x370E Not used
Timestamp
UINT32
UINT32
R
R
+60,61
+62,63
0x370F Maximum kW export sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+64,65
+66,67
0x3710 Maximum kvar export sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
38016-38063 Maximum Harmonic Demands
+0,1
+2,3
0x3880 V1/V12 THD demand
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
+4,5
+6,7
0x3881 V2/V23 THD demand
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
+8,9
+10,11
0x3882 V3/V31 THD demand
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
+12,13
+14,15
0x3883 Not used UINT32
UINT32
R
R
+16,17
+18,19
0x3884 I1 THD demand
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
+20,21
+22,23
0x3885 I2 THD demand
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
+24,25
+26,27
0x3886 I3 THD demand
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
+28,29
+30,31
0x3887 Not used UINT32
UINT32
R
R
+32,33
+34,35
0x3888 I1 TDD demand
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
+36,37
+38,39
0x3889 I2 TDD demand
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
+40,41
+42,43
0x388A I3 TDD demand
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
+44,45
+46,47
0x388B Not used UINT32
UINT32
R
R
38144-38175 TOU Maximum Demand Register #1
E
+0,1
+2,3
0x4800 Tariff #1 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+4,5
+6,7
0x4801 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x4807 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
38400-38431 TOU Maximum Demand Register #2
E
