Satec PM172P Reference Guide

43
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
… R
+14,15 0x3D07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
19712-19727 TOU Energy Register #2
E
+0,1 0x3E00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3E01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3E07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
19840-19855 TOU Energy Register #3
E
+0,1 0x3F00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3F01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3F07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
19968-19983 TOU Energy Register #4
E
+0,1 0x4000
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4001
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4007
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
20096-20111 TOU Energy Register #5
E
+0,1 0x4100
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4101
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4107
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
20224-20239 TOU Energy Register #6
E
+0,1 0x4200
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4201
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4207
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
20352-20367 TOU Energy Register #7
E
+0,1 0x4300
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4301
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4307
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
20480-20495 TOU Energy Register #8
E
+0,1 0x4400
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4401
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4407
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
20608-20623 Summary Energy Accumulated Demands
E
+0,1 0x4500
Summary register #1 demand
0-Pmax U3 UINT32 R
+2,3 0x4501
Summary register #2 demand
0-Pmax U3 UINT32 R
…
