Satec PM172P Reference Guide

30
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+14,15 0x3E07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9176-9191 TOU Energy Register #3
E
+0,1 0x3F00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3F01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3F07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9216-9231 TOU Energy Register #4
E
+0,1 0x4000
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4001
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4007
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9256-9271 TOU Energy Register #5
E
+0,1 0x4100
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4101
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4107
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9296-9311 TOU Energy Register #6
E
+0,1 0x4200
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4201
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4207
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9336-9351 TOU Energy Register #7
E
+0,1 0x4300
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4301
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4307
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9376-9391 TOU Energy Register #8
E
+0,1 0x4400
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4401
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4407
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
9416-9423 Summary Energy Accumulated Demands
E
+0 0x4500
Summary register #1 demand
0-Pmax U3 UINT16 R
+1 0x4501
Summary register #2 demand
0-Pmax U3 UINT16 R
… R
+7 0x4507
Summary register #8 demand
0-Pmax U3 UINT16 R
9436-9443 Summary Energy Block Demands
E
+0 0x4580
Summary register #1 demand
0-Pmax U3 UINT16 R
+1 0x4581
Summary register #2 demand
0-Pmax U3 UINT16 R
… R
+7 0x4587
Summary register #8 demand
0-Pmax U3 UINT16 R
