Satec PM172P Reference Guide

21
3.3 16-bit Scaled Analog Registers, Binary Registers and Counters
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
6656 0x0000 None 0 UINT16 R
6696-6697 Special Inputs
+0 0x0100
Voltage disturbance
EH
0-100 % UINT16 R
+1 0x0101 Phase rotation order 0=error, 1=positive (ABC),
2=negative (CBA)
UINT16 R
6776 0x0300 Event Flags (bitmap)
EH
0x0000-0x00FF UINT16 R
6896 0x0600 Digital Inputs (bitmap) 0x0000-0x0003 UINT16 R
6976 0x0800 Relay Outputs (bitmap) 0x0000-0x0003 UINT16 R
7056-7063 Counters
+0,1 0x0A00 Counter #1 0-999,999 UINT32 R/W
+2,3 0x0A01 Counter #2 0-999,999 UINT32 R/W
+4,5 0x0A02 Counter #3 0-999,999 UINT32 R/W
+6,7 0x0A03 Counter #4 0-999,999 UINT32 R/W
7136-7168 1-Cycle Phase Values
+0 0x0C00 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x0C01 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x0C02 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x0C03 I1 Current 0-Imax U2 UINT16 R
+4 0x0C04 I2 Current 0-Imax U2 UINT16 R
+5 0x0C05 I3 Current 0-Imax U2 UINT16 R
+6 0x0C06 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x0C07 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x0C08 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x0C09 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x0C0A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x0C0B kvar L3 -Pmax-Pmax U3 INT16 R
+12 0x0C0C kVA L1 0-Pmax U3 UINT16 R
+13 0x0C0D kVA L2 0-Pmax U3 UINT16 R
+14 0x0C0E kVA L3 0-Pmax U3 UINT16 R
+15 0x0C0F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x0C10 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x0C11 Power factor L3 -1.000-1.000 0.001 INT16 R
+18 0x0C12 V1/V12 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+19 0x0C13 V2/V23 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+20 0x0C14 V3/V31 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+21 0x0C15 I1 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+22 0x0C16 I2 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+23 0x0C17 I3 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+24 0x0C18 I1 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+25 0x0C19 I2 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
