Satec PM172P Reference Guide

28
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
8736-8765 Maximum 1-Cycle Phase Values
+0 0x3400 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x3401 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x3402 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x3403 I1 Current 0-Imax U2 UINT16 R
+4 0x3404 I2 Current 0-Imax U2 UINT16 R
+5 0x3405 I3 Current 0-Imax U2 UINT16 R
+6-17 0x3406-
0x3411
Not used 0 INT16 R
+18 0x3412 V1 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+19 0x3413 V2 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+20 0x3414 V3 Voltage THD 0-999.9 0.1% UINT16 R
1
4-cycle value
+21 0x3415 I1 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+22 0x3416 I2 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+23 0x3417 I3 Current THD 0-999.9 0.1% UINT16 R 4-cycle value
+24 0x3418 I1 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+25 0x3419 I2 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+26 0x341A I3 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+27 0x341B I1 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+28 0x341C I2 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+29 0x341D I3 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
8776-8779 Maximum 1-Cycle Total Values
+0 0x3500 Total kW -Pmax-Pmax U3 INT16 R
+1 0x3501 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x3502 Total kVA 0-Pmax U3 UINT16 R
+3 0x3503 Total PF 0-1.000 0.001 UINT16 R Absolute value
881608818 Maximum 1-Cycle Auxiliary Values
+0 0x3600 Not used U2 UINT16 R
+1 0x3601 In Current 0-Imax U2 UINT16 R
+2 0x3602 Frequency 0-Fmax 0.01Hz UINT16 R
8856-8872 Maximum Demands
+0 0x3700 V1/V12 Maximum volt demand 0-Vmax U1 UINT16 R
1
+1 0x3701 V2/V23 Maximum volt demand 0-Vmax U1 UINT16 R
1
+2 0x3702 V3/V31 Maximum volt demand 0-Vmax U1 UINT16 R
1
+3 0x3703 I1 Maximum ampere demand 0-Imax U2 UINT16 R
+4 0x3704 I2 Maximum ampere demand 0-Imax U2 UINT16 R
+5 0x3705 I3 Maximum ampere demand 0-Imax U2 UINT16 R
+6 0x3706 Not used UINT16 R
+7 0x3707 Not used UINT16 R
+8 0x3708 Not used UINT16 R
+9 0x3709 Maximum kW import sliding window demand 0-Pmax U3 UINT16 R
+10 0x370A Maximum kvar import sliding window demand 0-Pmax U3 UINT16 R
+11 0x370B Maximum kVA sliding window demand 0-Pmax U3 UINT16 R
