Satec PM172P Reference Guide

84
Format Code Value Description Notes
0x71 0x04
Data log #5
E
0x71 0x05
Data log #6
E
0x71 0x06
Data log #7
E
0x71 0x07
Data log #8
E
0x72 0x00
Waveform log #1
EH
0x73 0x00
Waveform log #2
EH
Counter Source ID
0x0000 None F16
0x0001-0x0002 Pulse input DI1-DI2
Relay Output Pulse Source ID
E
0x0000 None
0x0400 kWh import pulse
0x0401 kWh export pulse
0x0403 kvarh import pulse
0x0404 kvarh export pulse
0x0405 kvarh total pulse
F17
0x0406 kVAh pulse
AO/Analog Expander Output Parameters ID
0x0000 None (output disabled) Note 2
1-Cycle Phase Values
0x0C00 V1/V12 Voltage
0x0C01 V2/V23 Voltage
0x0C02 V3/V31 Voltage
0x0C03 I1 Current
0x0C04 I2 Current
0x0C05 I3 Current
0x0C1E V12 Voltage
0x0C1F V23 Voltage
0x0C20 V31 Voltage
1-Cycle Total Values
0x0F00 Total kW
0x0F01 Total kvar
0x0F02 Total kVA
0x0F03 Total PF
0x0F04 Total PF Lag
0x0F05 Total PF Lead
1-Cycle Auxiliary Values
0x1001 In Current
0x1002 Frequency
1-Sec Phase Values
0x1100 V1/V12 Voltage
0x1101 V2/V23 Voltage
0x1102 V3/V31 Voltage
0x1103 I1 Current
0x1104 I2 Current
0x1105 I3 Current
0x111E V12 Voltage
0x111F V23 Voltage
0x1120 V31 Voltage
1-Sec Total Values
0x1400 Total kW
0x1401 Total kvar
0x1402 Total kVA
0x1403 Total PF
0x1404 Total PF Lag
0x1405 Total PF Lead
1-Sec Auxiliary Values
0x1501 In Current
0x1502 Frequency
Present Demands
E
0x160F Accumulated kW import demand
0x1610 Accumulated kvar import demand
0x1611 Accumulated kVA demand
0x161A Accumulated kW export demand
F18
0x161B Accumulated kvar export demand
Event Cause/Point ID
F19 Setpoint Operation Events
