Satec PM172P Reference Guide

86
Format Code Value Description Notes
0x13 Programmable Min/Max log setup
0x14 Data log setup
0x15 File/Memory setup
0x16 TOU energy registers setup
0x18 TOU daily profiles
0x19 TOU calendar
0x1D RO Setup
0x1C User selectable options
0x1F DNP 3.0 Class 0 map
0x20 DNP 3.0 options setup
0x21 DNP 3.0 events setup
0x22 DNP 3.0 event setpoints
0x23 Calibration registers
0x24 Date/Time Setup
0x25 Net setup
0x26 AI setup
0x27 Waveform log setup
0x2B-0x3F Reserved
Device Diagnostics
Bit 0 Reserved
Bit 1 Reserved
Bit 2 = 1 RAM/Data error
Bit 3 = 1 CPU watchdog reset
Bit 4 = 1 Sampling fault
Bit 5 = 1 CPU exception
Bit 6 Reserved
Bit 7 = 1 Software watchdog reset
Bit 8 = 1 Power down
Bit 9 = 1 Device reset
Bit 10 = 1 Configuration reset
Bit 11 = 1 RTC fault
Bit 12 Reserved
Bit 13 = 1 Low battery
Bit 14 Reserved
F23
Bit 15 = 1 EEPROM fault
DNP Object Types
Static Binary Input Objects
0 Single-Bit Binary Input
1 Binary Input With Status
Binary Input Change Event Objects
0 Binary Input Change Without Time
1 Binary Input Change With Time
Static Binary Counters
0 32-bit Binary Counter
1 32-bit Binary Counter Without Flag
2 16-bit Binary Counter
3 16-bit Binary Counter Without Flag
Binary Counter Change Events
0 32-bit Counter Change Event Without Time
1 32-bit Counter Change Event With Time
2 16-bit Counter Change Event Without Time
3 16-bit Counter Change Event With Time
Frozen Binary Counters
0 32-bit Frozen Counter
1 32-bit Frozen Counter Without Flag
2 32-bit Frozen Counter With Time of Freeze
3 16-bit Frozen Counter
4 16-bit Frozen Counter Without Flag
5 16-bit Frozen Counter With Time of Freeze
Static Analog Input Objects
0 32-bit Analog Input
1 32-bit Analog Input Without Flag
2 16-bit Analog Input
3 16-bit Analog Input Without Flag
Analog Input Change Events
0 32-bit Analog Change Event Without Time
F24
1 32-bit Analog Change Event With Time
