Satec PM172P Reference Guide

61
Address Point ID Description Options/Range Units Type R/W Notes
1792-1807 Data log #1 Setup
1808-1823 Data log #2 Setup
1824-1839 Data log #3 Setup
1840-1855 Data log #4 Setup
1856-1871 Data log #5 Setup
1872-1887 Data log #6 Setup
1888-1903 Data log #7 Setup
1904-1919 Data log #8 Setup
Pulse Counters Setup
2940-2947
+0 Source digital input ID 0=not assigned, 1=DI1, 2=DI2 UINT16 R/W
+1 Multiplier 0-9999 UINT16 R/W
2940-2941 Counter #1 Setup
2942-2943 Counter #2 Setup
2944-2945 Counter #3 Setup
2946-2947 Counter #4 Setup
Analog Outputs Setup
3148-3153
+0 Output parameter ID F18 UINT16 R/W
+1 Zero scale value (0/4 mA) See Section 3.3 UINT16 R/W Scaled value
+2 Full scale value (1/20 mA) See Section 3.3 UINT16 R/W Scaled value
3148-3150 AO1 Setup
3151-3153 AO2 Setup
Analog Expander Setup
3196-3243 Analog expander outputs settings
will not be in effect until the analog
expander output is globally enabled
through the Device Options setup
+0 Output parameter ID F18 UINT16 R/W
+1 Zero scale value (0/4 mA) See Section 3.3 UINT16 R/W Scaled value
+2 Full scale value (1/20 mA) See Section 3.3 UINT16 R/W Scaled value
3196-3198 AX8 #1 Channel 1 Setup
3199-3201 AX8 #1 Channel 2 Setup
3202-3204 AX8 #1 Channel 3 Setup
3205-3207 AX8 #1 Channel 4 Setup
3208-3210 AX8 #1 Channel 5 Setup
3211-3213 AX8 #1 Channel 6 Setup
3214-3216 AX8 #1 Channel 7 Setup
3217-3219 AX8 #1 Channel 8 Setup
3220-3222 AX8 #2 Channel 1 Setup
3223-3225 AX8 #2 Channel 2 Setup
3226-3228 AX8 #2 Channel 3 Setup
3229-3231 AX8 #2 Channel 4 Setup
