Satec PM172P Reference Guide

83
Format Code Value Description Notes
0x1610 High accumulated kvar import demand
0x1611 High accumulated kVA demand
0x1612 High predicted kW import demand
0x1613 High predicted kvar import demand
0x1614 High predicted kVA demand
0x1616 High block kW export demand
0x1617 High block kvar export demand
0x1618 High sliding window kW export demand
0x1619 High sliding window kvar export demand
0x161A High accumulated kW export demand
0x161B High accumulated kvar export demand
0x161C High predicted kW export demand
0x161D High predicted kvar export demand
Setpoint Status
0x7C00 Setpoint #1 ON
0x7C01 Setpoint #2 ON
0x7C02 Setpoint #3 ON
0x7C03 Setpoint #4 ON
0x7C04 Setpoint #5 ON
0x7C05 Setpoint #6 ON
0x7C06 Setpoint #7 ON
0x7C07 Setpoint #8 ON
0x7C08 Setpoint #9 ON
0x7C09 Setpoint #10 ON
0x7C0A Setpoint #11 ON
0x7C0B Setpoint #12 ON
0x7C0C Setpoint #13 ON
0x7C0D Setpoint #14 ON
0x7C0E Setpoint #15 ON
0x7C0F Setpoint #16 ON
Setpoint Action ID
Action type Target
0x00 0x00 No action
0x20 0x00
Set Event flag #1
EH
0x20 0x01
Set Event flag #2
EH
0x20 0x02
Set Event flag #3
EH
0x20 0x03
Set Event flag #4
EH
0x21 0x00
Clear Event flag #1
EH
0x21 0x01
Clear Event flag #2
EH
0x21 0x02
Clear Event flag #3
EH
0x21 0x03
Clear Event flag #4
EH
0x30 0x00 Operate Relay #1
0x30 0x01 Operate Relay #2
0x31 0x00 Release latched Relay #1
0x31 0x01 Release latched Relay #2
0x40 0x00 Increment counter #1
0x40 0x01 Increment counter #2
0x40 0x02 Increment counter #3
0x40 0x03 Increment counter #4
0x41 0x00 Clear counter #1
0x41 0x01 Clear counter #2
0x41 0x02 Clear counter #3
0x41 0x03 Clear counter #4
0x64 0x00 Clear all counters
0x51 0x00 Send event notification
0x60 0x00
Reset total energy
E
0x61 0x00 Reset all total maximum demands
0x61 0x01
Reset power maximum demands
E
0x61 0x02 Reset volt/ampere/harmonic maximum demands
0x62 0x00
Reset TOU energy
E
0x63 0x00
Reset TOU maximum demands
E
0x65 0x00 Clear Min/Max registers
0x70 0x02
Event log
E
0x71 0x00
Data log #1
E
0x71 0x01
Data log #2
E
0x71 0x02
Data log #3
E
F14
0x71 0x03
Data log #4
E
