Satec PM172P Reference Guide

36
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+28,29 0x108E I3 Current angle -1800-1800
×0.1º
INT32 R
+30,31 0x108F Not used INT32 R
13952-14017 1-Second Phase Values
+0,1 0x1100 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
+2,3 0x1101 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
+4,5 0x1102 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
+6,7 0x1103 I1 Current 0-Imax U2 UINT32 R
+8,9 0x1104 I2 Current 0-Imax U2 UINT32 R
+10,11 0x1105 I3 Current 0-Imax U2 UINT32 R
+12,13 0x1106 kW L1 -Pmax-Pmax U3 INT32 R
+14,15 0x1107 kW L2 -Pmax-Pmax U3 INT32 R
+16,17 0x1108 kW L3 -Pmax-Pmax U3 INT32 R
+18,19 0x1109 kvar L1 -Pmax-Pmax U3 INT32 R
+20,21 0x110A kvar L2 -Pmax-Pmax U3 INT32 R
+22,23 0x110B kvar L3 -Pmax-Pmax U3 INT32 R
+24,25 0x110C kVA L1 0-Pmax U3 UINT32 R
+26,27 0x110D kVA L2 0-Pmax U3 UINT32 R
+28,29 0x110E kVA L3 0-Pmax U3 UINT32 R
+30,31 0x110F Power factor L1 -1000-1000
×0.001
INT32 R
+32,33 0x1110 Power factor L2 -1000-1000
×0.001
INT32 R
+34,35 0x1111 Power factor L3 -1000-1000
×0.001
INT32 R
+36,37 0x1112 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
1
3-sec value
+38,39 0x1113 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
1
3-sec value
+40,41 0x1114 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
1
3-sec value
+42,43 0x1115 I1 Current THD 0-9999
×0.1%
UINT32 R 3-sec value
+44,45 0x1116 I2 Current THD 0-9999
×0.1%
UINT32 R 3-sec value
+46,47 0x1117 I3 Current THD 0-9999
×0.1%
UINT32 R 3-sec value
+48,49 0x1118 I1 K-Factor 10-9999
×0.1
UINT32 R 3-sec value
+50,51 0x1119 I2 K-Factor 10-9999
×0.1
UINT32 R 3-sec value
+52,53 0x111A I3 K-Factor 10-9999
×0.1
UINT32 R 3-sec value
+54,55 0x111B I1 Current TDD 0-1000
×0.1%
UINT32 R 3-sec value
+56,57 0x111C I2 Current TDD 0-1000
×0.1%
UINT32 R 3-sec value
+58,59 0x111D I3 Current TDD 0-1000
×0.1%
UINT32 R 3-sec value
+60,61 0x111E V12 Voltage 0-Vmax U1 UINT32 R
+62,63 0x111F V23 Voltage 0-Vmax U1 UINT32 R
+64,65 0x1120 V31 Voltage 0-Vmax U1 UINT32 R
14336-14343 1-Second Total Values
+0,1 0x1400 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x1401 Total kvar -Pmax-Pmax U3 INT32 R
+4,5 0x1402 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x1403 Total PF -1000-1000
×0.001
INT32 R
+8,9 0x1404 Total PF lag 0-1000
×0.001
UINT16 R
+10,11 0x1405 Total PF lead 0-1000
×0.001
UINT16 R
