Satec PM172P Reference Guide

57
Address Point ID Description Options/Range Units Type R/W Notes
interval.
E
+4 Volt/ampere/harmonic demand period 0 to 1800 sec UINT16 R/W
+5-7 Reserved UINT16 R/W Read as 65535
+8
Number of blocks in a sliding window
E
1 to 15 UINT16 R/W
E
+9 Reserved UINT16 R/W Read as 65535
+10 Number of cycles before trigger for the Waveform log
#1
EH
1 to 8 UINT16 R/W Obsolete register. Refer to the
Waveform Log setup registers.
EH
+11 Nominal line frequency 25, 50, 60, 400 Hz UINT16 R/W
+12 Maximum demand load current 0 to 20,000 (0 = CT primary
current)
A UINT16 R/W
+13-15 Reserved UINT16 R/W Read as 65535
+16 Number of cycles per series for the Waveform log #1
EH
16 to 2560 UINT16 R/W Obsolete register. Refer to the
Waveform Log setup registers.
EH
+17 Reserved UINT16 R/W Read as 65535
+18
Nominal secondary voltage
EH
10 to 690 V UINT16 R/W
EH
+19 Reserved UINT16 R/W Read as 65535
+20 PT ratio multiplication factor
×1, ×10
UINT16 R/W
Communication Ports Setup
2344-2359
+0 Communication protocol COM1: 0=SATEC ASCII, 1=Modbus
RTU, 2=DNP3.0, 4=DTE,
5=Profibus DP
COM2: 0=SATEC ASCII, 1=Modbus
RTU, 2=DNP3.0, 4=DTE
UINT16 R/W
+1 Interface COM1: 0=RS-232, 1=RS-422,
2=RS-485, 4=Dial-up Modem,
6=Ethernet, 7=Profibus,
8=GSM/GPRS
COM2: 1=RS-422, 2=RS-485
UINT16 R/W
+2 Device address SATEC ASCII: 0-99
Modbus RTU: 1-247
DNP3.0: 0–65532
DTE: 1-65532
Profibus DP: 0-126
UINT16 R/W
+3 Baud rate 1=300 bps, 2=600 bps, 3=1200
bps, 4=2400 bps, 5=4800 bps,
6=9600 bps, 7=19200 bps,
8=38400 bps, 9=57600 bps,
10=115200 bps
UINT16 R/W
+4 Data format 0=7 bits/even parity,
1=8 bits/no parity,
2=8 bits/even parity
UINT16 R/W
+5 Flow control 0=no flow control
1=software (XON/XOFF)
UINT16 R/W N/A for COM2 (read as 65535)
