Satec PM172P Reference Guide

34
3.4 32-bit Analog Registers, Binary Registers and Counters
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
11776-11777 0x0000 None 0 UINT32 R
11904-11907 Special Inputs
+0,1 0x0100
Voltage disturbance
EH
0-100 % UINT32 R
+2,3 0x0101 Phase rotation order 0=error, 1=positive (ABC),
2=negative (CBA)
UINT32 R
12160-12161 0x0300 Event Flags (bitmap)
EH
0x00000000-0x000000FF UINT32 R
12544-12545 0x0600 Digital Inputs DI1-DI2 (bitmap) 0x00000000-0x00000003 UINT32 R
12800-12801 0x0800 Relay Outputs RO1-RO2 (bitmap) 0x00000000-0x00000003 UINT32 R
13056-13063 Counters
+0,1 0x0A00 Counter #1 0-999,999 UINT32 R/W
+2,3 0x0A01 Counter #2 0-999,999 UINT32 R/W
+4,5 0x0A02 Counter #3 0-999,999 UINT32 R/W
+6,7 0x0A03 Counter #4 0-999,999 UINT32 R/W
13312-13377 1-Cycle Phase Values
+0,1 0x0C00 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
+2,3 0x0C01 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
+4,5 0x0C02 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
+6,7 0x0C03 I1 Current 0-Imax U2 UINT32 R
+8,9 0x0C04 I2 Current 0-Imax U2 UINT32 R
+10,11 0x0C05 I3 Current 0-Imax U2 UINT32 R
+12,13 0x0C06 kW L1 -Pmax-Pmax U3 INT32 R
+14,15 0x0C07 kW L2 -Pmax-Pmax U3 INT32 R
+16,17 0x0C08 kW L3 -Pmax-Pmax U3 INT32 R
+18,19 0x0C09 kvar L1 -Pmax-Pmax U3 INT32 R
+20,21 0x0C0A kvar L2 -Pmax-Pmax U3 INT32 R
+22,23 0x0C0B kvar L3 -Pmax-Pmax U3 INT32 R
+24,25 0x0C0C kVA L1 0-Pmax U3 UINT32 R
+26,27 0x0C0D kVA L2 0-Pmax U3 UINT32 R
+28,29 0x0C0E kVA L3 0-Pmax U3 UINT32 R
+30,31 0x0C0F Power factor L1 -1000-1000
×0.001
INT32 R
+32,33 0x0C10 Power factor L2 -1000-1000
×0.001
INT32 R
+34,35 0x0C11 Power factor L3 -1000-1000
×0.001
INT32 R
+36,37 0x0C12 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+38,39 0x0C13 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+40,41 0x0C14 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
1
4-cycle value
+42,43 0x0C15 I1 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+44,45 0x0C16 I2 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+46,47 0x0C17 I3 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
+48,49 0x0C18 I1 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
