Satec PM172P Reference Guide

46
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+0,1 0x6A00
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6A01
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+78,79 0x6A27
H40 Harmonic angle
-1800-1800
×0.1º
INT32 R
Generic TOU Season Energy Registers ID’s
E
Point references only
0x7000
Tariff #1 register
0-999,999,999 1 kWh UINT32
0x7001
Tariff #2 register
0-999,999,999 1 kWh UINT32
…
0x7007
Tariff #8 register
0-999,999,999 1 kWh UINT32
Generic TOU Season Maximum Demand
Registers ID’s
E
Point references only
0x7100
Tariff #1 register
0-Pmax U3 UINT32
0x7101
Tariff #2 register
0-Pmax U3 UINT32
…
0x7107
Tariff #8 register
0-Pmax U3 UINT32
27648-27649 0x7C00 Setpoint Status SP1-SP16 (bitmap) 0x00000000-0x0000FFFF UINT32 R
NOTES:
Energy and Power demand readings are only available in the meters with suffixes E and EH.
1
Voltage and Voltage Harmonics Readings:
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
When the 4LN3, 4LL3, 3LN3, 3LL3, 3BLN3 or 3BLL3 wiring mode is selected, the voltage harmonics will be line-to-neutral; for any other wiring mode, they will be line-to-line.
2
For volts, amps, power and frequency scales and units, refer to Section 4 ”Data Scales and Units”.
3
Harmonic angles are referenced to the fundamental voltage harmonic H01 on phase L1.
3.5 Minimum/Maximum Log Registers
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
35840-35959 Minimum Phase Values
+0,1
+2,3
0x2C00 Min. V1/V12 Voltage
Timestamp
0-Vmax
F1
U1
sec
UINT32
UINT32
R
R
1
+4,5
+6,7
0x2C01 Min. V2/V23 Voltage
Timestamp
0-Vmax
F1
U1
sec
UINT32
UINT32
R
R
1
+8,9
+10,11
0x2C02 Min. V3/V31 Voltage
Timestamp
0-Vmax
F1
U1
sec
UINT32
UINT32
R
R
1
+12,13
+14,15
0x2C03 Min. I1 Current
Timestamp
0-Imax
F1
U2
sec
UINT32
UINT32
R
R
+16,17
+18,19
0x2C04 Min. I2 Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+20,21 0x2C05 Min. I3 Current 0-Imax U2 UINT32 R
