Satec PM172P Reference Guide

32
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
9656-9663 TOU Maximum Demand Register #7
E
+0 0x5300
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x5301
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x5307
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9676-9683 TOU Maximum Demand Register #8
E
+0 0x5380
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x5381
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x5387
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
10656-10695 V1/V12 Harmonic Angles
EH 1, 3
+0 0x6400
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6401
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+39 0x6427
H40 Harmonic angle
-180.0-180.0 0.1º INT16 R
10696-10735 V2/V23 Harmonic Angles
EH 1, 3
+0 0x6500
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6501
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+39 0x6527
H40 Harmonic angle
-180.0-180.0 0.1º INT16 R
10736-10775 V1/V31 Harmonic Angles
EH 1, 3
+0 0x6600
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6601
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+39 0x6627
H40 Harmonic angle
-180.0-180.0 0.1º INT16 R
10816-10855 I1 Harmonic Angles
EH 3
+0 0x6800
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6801
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+39 0x6827
H40 Harmonic angle
-180.0-180.0 0.1º INT16 R
10856-10895 I2 Harmonic Angles
EH 3
+0 0x6900
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6901
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+39 0x6927
H40 Harmonic angle
-180.0-180.0 0.1º INT16 R
10896-10935 I3 Harmonic Angles
EH 3
+0 0x6A00
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6A01
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+39 0x6A27
H40 Harmonic angle
-180.0-180.0 0.1º INT16 R
