Satec PM172P Reference Guide

25
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+17 0x1611 kVA accumulated demand 0-Pmax U3 UINT16 R
+18 0x1612 kW import predicted sliding window demand 0-Pmax U3 UINT16 R
+19 0x1613 kvar import predicted sliding window demand 0-Pmax U3 UINT16 R
+20 0x1614 kVA predicted sliding window demand 0-Pmax U3 UINT16 R
+21 0x1615 PF (import) at Max. kVA sliding window demand 0-1.000 0.001 UINT16 R
+22 0x1616 kW export block demand 0-Pmax U3 UINT16 R
+23 0x1617 kvar export block demand 0-Pmax U3 UINT16 R
+24 0x1618 kW export sliding window demand 0-Pmax U3 UINT16 R
+25 0x1619 kvar export sliding window demand 0-Pmax U3 UINT16 R
+26 0x161A kW export accumulated demand 0-Pmax U3 UINT16 R
+27 0x161B kvar export accumulated demand 0-Pmax U3 UINT16 R
+28 0x161C kW export predicted sliding window demand 0-Pmax U3 UINT16 R
+29 0x161D kvar export predicted sliding window demand 0-Pmax U3 UINT16 R
7576-7611 Total Energies
E
+0,1 0x1700
kWh import
0-999,999,999 1 kWh UINT32 R
+2,3 0x1701 kWh export 0-999,999,999 1 kWh UINT32 R
+4,5 Not used INT32 R
+6,7 Not used UINT32 R
+8,9 0x1704 kvarh import 0-999,999,999 1 kvarh UINT32 R
+10,11 0x1705 kvarh export 0-999,999,999 1 kvarh UINT32 R
+12,13 Not used INT32 R
+14,15 Not used UINT32 R
+16,17 0x1708 kVAh total 0-999,999,999 1 kVAh UINT32 R
+18-25 Not used UINT32 R
+26,27 0x170D
Harmonic kWh import
EH
0-999,999,999 1 kWh UINT32 R
+28,29 0x170E
Harmonic kWh export
EH
0-999,999,999 1 kWh UINT32 R
+30-33 Not used UINT32 R
+34,35 0x1711
Harmonic kVAh total
EH
0-999,999,999 1 kVAh UINT32 R
7616-7633 Phase Energies
E
+0,1 0x1800
kWh import L1
0-999,999,999 1 kWh UINT32 R
+2,3 0x1801
kWh import L2
0-999,999,999 1 kWh UINT32 R
+4,5 0x1802
kWh import L3
0-999,999,999 1 kWh UINT32 R
+6,7 0x1803 kvarh import L1 0-999,999,999 1 kvarh UINT32 R
+8,9 0x1804 kvarh import L2 0-999,999,999 1 kvarh UINT32 R
+10,11 0x1805 kvarh import L3 0-999,999,999 1 kvarh UINT32 R
+12,13 0x1806 kVAh total L1 0-999,999,999 1 kVAh UINT32 R
+14,15 0x1807 kVAh total L2 0-999,999,999 1 kVAh UINT32 R
+16,17 0x1808 kVAh total L3 0-999,999,999 1 kVAh UINT32 R
7656-7695 V1/V12 Harmonic Distortions
EH 1
+0 0x1900
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1901
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
