Satec PM172P Reference Guide

62
Address Point ID Description Options/Range Units Type R/W Notes
3232-3234 AX8 #2 Channel 5 Setup
3235-3237 AX8 #2 Channel 6 Setup
3238-3240 AX8 #2 Channel 7 Setup
3241-3243 AX8 #2 Channel 8 Setup
Digital Inputs Setup
3292-3296 Obsolete registers. Refer to Digital
Inputs setup registers 61728-61735
+0 Status inputs (bitmap) 0x0003 UINT16 R/W Ignored when written
+1 Pulse inputs (bitmap) 0x0003 UINT16 R/W Ignored when written
+2 Not used 0 UINT16 R/W
+3 External demand synchronization input (bitmap) 0x0001=DI1 UINT16 R/W Ignored when written
+4 Time synchronization input (bitmap) 0x0001=DI1, 0x0002=DI2 UINT16 R/W
Periodic Timers Setup
E
3300-3301
+0 Time interval 0=timer disabled, 1-9999 sec sec UINT16 R/W
3300 Timer #1 Setup UINT16 R/W
3301 Timer #2 Setup UINT16 R/W
File Setup
E
3660-3811
+0 Number of records in the file 0=delete a file, 1-65535 UINT16 R/W
+1 Number of parameters per record 1-16 UINT16 R/W Write 0 for event and waveform log
files
+2 File attributes (bitmap) F3 UINT16 R/W
+3 File record size, bytes (for info only) UINT16 R
+4,5 Allocated file size, bytes (for info only) UINT32 R
+6,7 Reserved UINT16 R
3660-3667 Event Log Setup
3668-3675 Data Log #1 Setup
3676-3683 Data Log #2 Setup
3684-3691 Data Log #3 Setup
3692-3699 Data Log #4 Setup
3700-3707 Data Log #5 Setup
3708-3715 Data Log #6 Setup
3716-3723 Data Log #7 Setup
3724-3729 Data Log #8 Setup
3730-3795 Reserved
3796-3803 Waveform Log #1 Setup
3804-3811 Waveform Log #2 Setup
Network Setup
46576-46703
+0,1 Device IP Address 0x01000000-0xFFFFFFFF UINT32 R/W Network byte order
+2,3 Network subnet mask 0x00000001-0xFFFFFFFF UINT32 R/W Network byte order
