42
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+12,13 0x3706 Not used UINT32 R
+14,15 0x3707 Not used UINT32 R
+16,17 0x3708 Not used UINT32 R
+18,19 0x3709 Maximum kW import sliding window demand 0-Pmax U3 UINT32 R
+20,21 0x370A Maximum kvar import sliding window demand 0-Pmax U3 UINT32 R
+22,23 0x370B Maximum kVA sliding window demand 0-Pmax U3 UINT32 R
+24,25 0x3737 Not used UINT32 R
+26,27 0x370D Not used UINT32 R
+28,29 0x370E Not used UINT32 R
+30,31 0x370F Maximum kW export sliding window demand 0-Pmax U3 UINT32 R
+32,33 0x3710 Maximum kvar export sliding window demand 0-Pmax U3 UINT32 R
18984-19007 Maximum Harmonic Demands
+0,1 0x3880 V1/V12 THD demand 0-9999
×0.1%
UINT32 R
1
+2,3 0x3881 V2/V23 THD demand 0-9999
×0.1%
UINT32 R
1
+4,5 0x3882 V3/V31 THD demand 0-9999
×0.1%
UINT32 R
1
+6,7 0x3883 Not used UINT32 R
+8,9 0x3884 I1 THD demand 0-9999
×0.1%
UINT32 R
+10,11 0x3885 I2 THD demand 0-9999
×0.1%
UINT32 R
+12,13 0x3886 I3 THD demand 0-9999
×0.1%
UINT32 R
+14,15 0x3887 Not used UINT32 R
+16,17 0x3888 I1 TDD demand 0-1000
×0.1%
UINT32 R
+18,19 0x3889 I2 TDD demand 0-1000
×0.1%
UINT32 R
+20,21 0x388A I3 TDD demand 0-1000
×0.1%
UINT32 R
+22,23 0x388B Not used UINT32 R
19328-19359 Scaled Analog Inputs
+0,1 0x3B00 Analog input AI1 AI1min-AI1Max UINT32 R
+2,3 0x3B01 Analog input AI2 AI2min-AI2Max UINT32 R
19368-19371 Raw Analog Inputs
+0,1 0x3B80 Analog input AI1 0-4095 UINT32 R
+2,3 0x3B81 Analog input AI2 0-4095 UINT32 R
19456-19459 TOU Parameters
E
+0,1 0x3C00 Active tariff 0-7 UINT32 R
+2,3 0x3C01 Active profile 0-15:
1-3 = Season 1 Profile #1-4,
4-7 = Season 2 Profile #1-4,
8-11 = Season 3 Profile #1-4,
12-15 = Season 4 Profile #1-4
UINT32 R
19496-19499 Scaled Analog Outputs
+0,1 0x3C80 Analog output AO1 0-4095 UINT32 R/W
+2,3 0x3C81 Analog output AO2 0-4095 UINT32 R/W
19584-19599 TOU Energy Register #1
E
+0,1 0x3D00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3D01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
