Satec PM172P Reference Guide

48
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
36864-36983 Maximum Phase Values
+0,1
+2,3
0x3400 Max. V1/V12 Voltage
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+4,5
+6,7
0x3401 Max. V2/V23 Voltage
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+8,9
+10,11
0x3402 Max. V3/V31 Voltage
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+12,13
+14,15
0x3403 Max. I1 Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+16,17
+18,19
0x3404 Max. I2 Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+20,21
+22,23
0x3405 Max. I3 Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+24-71 0x3406-
0x3411
Not used 0 INT32 R
+72,73
+74,75
0x3412 Max. V1/V12 Voltage THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+76,77
+78,79
0x3413 Max. V2/V23 Voltage THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+80,81
+82,83
0x3414 Max. V3/V31 Voltage THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+84,85
+86,87
0x3415 Max. I1 Current THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+88,89
+90,91
0x3416 Max. I2 Current THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+92,93
+94,95
0x3417 Max. I3 Current THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+96,97
+98,99
0x3418 Max. I1 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
4-cycle value
+100,101
+102,103
0x3419 Max. I2 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
4-cycle value
+104,105
+106,107
0x341A Max. I3 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
4-cycle value
+108,109
+110,111
0x341B Max. I1 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+112,113
+114,115
0x341C Max. I2 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+116,117
+118,119
0x341D Max. I3 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
37120-37135 Maximum Total Values
+0,1
+2,3
0x3500 Max. Total kW
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
+4,5
+6,7
0x3501 Max. Total kvar
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
