Satec PM172P Reference Guide

66
Address Point ID Description Options/Range Units Type R/W Notes
51702-51704
DNP Class 0 Points Group 1
51705-51707
DNP Class 0 Points Group 2
…
51795-51797 DNP Class 0 Points Group 32
51798-51893 Reserved
Waveform Recorder Setup
EH
53878-53949
+0 Sampling rate, samples per cycle 32 (Waveform log #1),
128 (Waveform log #2)
UINT16 R/W Ignored when written
+1 Number of cycles per series 16-2560 (32 samples/cycle),
4-640 (128 samples/cycle)
UINT16 R/W
+3 Not used 0 UINT16 R/W
+4 Number of cycles before a trigger 1-20 UINT16 R/W
+4,5 File channel mask, bitmap F9, 0x00000033 UINT32 R/W Ignored when written
+6,7 Not used 0 UINT32 R/W
53878-53885 Waveform Log #1 Setup
53886-53893 Waveform Log #2 Setup
TOU Daily Profile Setup
E
55574-55701
+0 1
st
tariff change F10 UINT16 R/W
+1 2
nd
tariff change F10 UINT16 R/W
+2 3
rd
tariff change F10 UINT16 R/W
+3 4
th
tariff change F10 UINT16 R/W
+4 5
th
tariff change F10 UINT16 R/W
+5 6
th
tariff change F10 UINT16 R/W
+6 7
th
tariff change F10 UINT16 R/W
+7 8
th
tariff change F10 UINT16 R/W
55574-55581 Daily profile #1: Season 1, Day type 1
55582-55589 Daily profile #2: Season 1, Day type 2
55590-55597 Daily profile #3: Season 1, Day type 3
55598-55605 Daily profile #4: Season 1, Day type 4
55606-55613 Daily profile #5: Season 2, Day type 1
55614-55621 Daily profile #6: Season 2, Day type 2
55622-55629 Daily profile #7: Season 2, Day type 3
55630-55637 Daily profile #8: Season 2, Day type 4
55638-55645 Daily profile #9: Season 3, Day type 1
55646-55653 Daily profile #10: Season 3, Day type 2
55654-55661 Daily profile #11: Season 3, Day type 3
55662-55669 Daily profile #12: Season 3, Day type 4
55670-55677 Daily profile #13: Season 4, Day type 1
55678-55685 Daily profile #14: Season 4, Day type 2
55686-55693 Daily profile #15: Season 4, Day type 3
