Satec PM172P - TOU Maximum Demand Register #8

52
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
+4,5
+6,7
0x5301 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x5307 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
39040-39071 TOU Maximum Demand Register #8
E
+0,1
+2,3
0x5380 Tariff #1 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+4,5
+6,7
0x5381 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x5387 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
NOTES:
Power demand readings are only available in the meters with suffixes E and EH.
1
Voltage and Voltage Harmonics Readings:
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
When the 4LN3, 4LL3, 3LN3, 3LL3, 3BLN3 or 3BLL3 wiring mode is selected, the voltage harmonics will be line-to-neutral; for any other wiring mode, they will be line-to-line.
2
For volts, amps, power and frequency scales and units, refer to Section 4 ”Data Scales and Units”.
