Satec PM172P Reference Guide

72
Address Point ID Description Options/Range Units Type R/W Notes
+2 Number of the new records never read before 0 to 65535 UINT16 R
+3 Sequence number of the last record in a file + 1
(modulo 65536)
0 to 65535 (increments modulo
65536 with each new record)
UINT16 R Will return zero if the file is empty
+4 Sequence number of the first (oldest) record in a file 0 to 65535 UINT16 R
+5 Sequence number of the first new record in a file
never read before
0 to 65535 UINT16 R
+6 Sequence number of the current record to be read
through the file read window. Can be overwritten to
point to the desired record in a file
0 to 65535 UINT16 R/W If there is no a record in the file
that matches the written sequence,
the device will respond with the
exception code 03 (invalid data)
+7 Command register (write-only) Write value:
0 = point to the first (oldest) record
in a file
1 = point to the first new record
never read before. If there are no
new records, the file pointer will be
set to the oldest record in a file
UINT16 R/W Read as 0
28160-28167 Event log file control UINT16 R
28168-28175 Data log #1 file control UINT16 R
28176-28183 Data log #2 file control UINT16 R
28184-28191 Data log #3 file control UINT16 R
28192-28199 Data log #4 file control UINT16 R
28200-28207 Data log #5 file control UINT16 R
28208-28215 Data log #6 file control UINT16 R
28216-28223 Data log #7 file control UINT16 R
28224-28231 Data log #8 file control UINT16 R
28232-28295 Reserved UINT16 R
28296-28303 Waveform log #1 file control UINT16 R
28304-28311 Waveform log #2 file control UINT16 R
28312-28671 Reserved UINT16 R
28672-28679 Daily Profile Log, Energy/Usage Reg.#1 control UINT16 R
28680-28687 Daily Profile Log, Energy/Usage Reg.#2 control UINT16 R
28688-28695 Daily Profile Log, Energy/Usage Reg.#3 control UINT16 R
28696-28703 Daily Profile Log, Energy/Usage Reg.#4 control UINT16 R
28704-28711 Daily Profile Log, Energy/Usage Reg.#5 control UINT16 R
28712-28719 Daily Profile Log, Energy/Usage Reg.#6 control UINT16 R
28720-28727 Daily Profile Log, Energy/Usage Reg.#7 control UINT16 R
28728-28735 Daily Profile Log, Energy/Usage Reg.#8 control UINT16 R
28736-28799 Reserved UINT16 R
28800-28807 Daily Profile Log, Max. Demand Reg.#1 control UINT16 R
28808-28815 Daily Profile Log, Max. Demand Reg.#2 control UINT16 R
28816-28823 Daily Profile Log, Max. Demand Reg.#3 control UINT16 R
28824-28823 Daily Profile Log, Max. Demand Reg.#4 control UINT16 R
28832-28839 Daily Profile Log, Max. Demand Reg.#5 control UINT16 R
