78
File
Channel/
Section
1
Record
Field No.
2
Point Label Point
ID
Description Range
Units
3
Type Notes
6 TRF5 MD 0x7104 Tariff #5 max. demand reading 0-Pmax U3 UINT32
7 TRF6 MD 0x7105 Tariff #6 max. demand reading 0-Pmax U3 UINT32
8 TRF7 MD 0x7106 Tariff #7 max. demand reading 0-Pmax U3 UINT32
9 TRF8 MD 0x7107 Tariff #8 max. demand reading 0-Pmax U3 UINT32
1
An energy use profile section is allocated for registers for which a source input is selected in the Summary/TOU Register setup and for which energy use profile is enabled. A maximum
demand profile section is allocated for registers for which maximum demand profile is enabled in the Summary/TOU Register setup. Not configured sections/channels are not available for
download. Refer to the file channel mask in the file info for configured channels.
2
The number of parameters in a section is automatically configured depending on the number of actually used tariffs selected in the TOU Daily Profiles.
3
For power scale and units, refer to Section 4 ”Data Scales and Units”.
