5.04 2 Data Box & Data Box Options
5.04 2 Data Box Layout
(GPS Map → MAIN MENU → Settings → 2
Data Box Layout)
2 or 4 data box overlays (sections 5.05 &
5.06) are available on the GPS Map screen
(section 3.00). Toggle selections by pressing
the lower left side button.
For both the Left Box and the Right Box:
• Use the joystick, moving left/right to select
the desired option.
• Press Done or centre press the joystick to
return to SETTINGS MENU.
Pressing the Default button restores the
following settings:
Choose Data for Left Box
Heading
Choose Data for Right Box
Elevation
5.04a Data Options for 2-box and 4-box
data elds for overlays
(GPS Map → MAIN MENU → Settings → 2/4
Data Box Layout)
The following choices of data are available
by moving left/right using the joystick and
either selecting Done or centre pressing the
joystick. The same data options are available
for each box in both the 2-box and 4-box
layouts. For each data option a summary
descriptor is given on-screen.
Heading
Direction of travel, given in either Degrees
(M – Magnetic North, G – Grid North, T –
True North), Cardinal points (eg. N, NNE), or
mil-radians (section 15.00). See Compass
Settings (section 5.10).
Location
GPS position given by either OSGB
(Ordnance Survey GB); German Grid; UTM;
MGRS; CH1903/LV03 Swiss Grid; Degrees
decimal; Degrees, minutes decimal; Degrees,
minutes, seconds decimal; British Grid.
See GPS Settings, section 5.07.
GoTo Bearing
Bearing to your “Go To” point. See POSITION
INFO, section 8.00 (Set as GoTo option).
GoTo Distance
Distance to GoTo point, either imperial or
metric. See Units and Set Speed, section
5.09.
GoTo ETA
Estimated Time of Arrival at GoTo point.
GoTo Time
How long to reach GoTo point.
GoTo VMG
Following variation to the pre-planned route;
this new, corrected speed (Velocity Made
Good) is required to reach the GoTo point
in the original time planned. This is xed by
the target speed. See Units and Set Speed,
section 5.09 (Target Speed).
Bearing Next WP
Bearing to the next WayPoint.
Distance Next WP
Distance to the next WayPoint.
ETA to Next
Estimated Time of Arrival at next WayPoint.
Time Next
How long to reach next WayPoint.
VMG Next
Velocity Made Good to next WayPoint. See
GoTo VMG summary above.
WP Name
Name of next WayPoint.
Nearest POI
Name of nearest Points Of Interest. See
Points of Interest, section 9.00.
Bearing to POI
Bearing to nearest Waypoint.
Nearest POI Distance Distance to nearest
Point Of Interest.
POI ETA
Time until nearest Point Of Interest.
POI Time
Time of arrival at nearest Point Of Interest.
POI VMG
Velocity Made Good to nearest Point Of
Interest. See GoTo VMG summary above.
