4 Operation and Configuration
113
S84-ex/S86-ex Operator Manual
SLOT SETTING
Select whether or not to set the memory storage allocation for use with the
Memory card command <CC>.
• YES: Proceed to change the storage allocation for the memory slot.
• NO: No change to the memory slot.
Note
Refer to the Programming reference for details on the command.
button
Select “SETTING
SAVE” + button
button
Select “SETTING
UPLOAD” + button
button
Saving
completed?
Yes
No
Reading the data
Writing the data
Finished receiving the uploaded data
Finished writing the uploaded data
3 short beeps when saving to
memory is completed
button
Update
completed?
Yes
No
Reading the data
Writing the data
Finished receiving the uploaded data
Finished writing the uploaded data
3 short beeps when the upload
is completed
