8 Appendix
356
S84-ex/S86-ex Operator Manual
8.13
Interface Specifications
For data communication with the host, this printer supports the following interfaces:
You can set the various interface settings of the printer through the Interface Mode menu.
• USB (USB type B)
• LAN Ethernet
• RS-232C (DB 9 pins, female)
• IEEE1284 (Amphenol 36 pins)
• External signal (EXT) (DB 25 pins, female)
• Optional Bluetooth
• Optional Wireless LAN
CAUTION
Do not connect or disconnect the interface cables (or use a switch box) with power supplied to either the
printer or host. This may cause damage to the interface circuitry in the printer or host and is not covered by
warranty.
Note
• Bluetooth and wireless LAN are optional interfaces.
• You cannot use the wireless LAN interface and USB interface at a time.
